Water meter with optional telemetry
VADTel-WM-15
DN 15 mechanical water meter with an optional add-on cellular telemetry module for residential and light commercial AMR and AMI.
-
Automated meter reading
With the telemetry module fitted, readings reach the Data Platform without manual visits.
-
Telemetry as an add-on
The VAD-UM-01 module is optional and runs on its own battery — independent of the metrology.
-
MID-certified
MID (2014/32/EU, MI-001) to the EN ISO 4064 series for billing.
VADTel-WM-15 is the entry point of the VAD water-metering portfolio: a mechanical DN 15 meter that becomes an AMR or AMI endpoint with the add-on VAD-UM-01 telemetry module. Readings, archive access and consumption analytics then run on the Data Platform.
Full documentation is available on the IoT documentation portal.
| Metering | |
|---|---|
| Meter type | Mechanical, roller register |
| Nominal diameter | DN 15 |
| Rating | MAP 16 / T50 |
| Application | Residential and light commercial AMR and AMI |
| Telemetry | |
| Module | VAD-UM-01, optional add-on |
| Cellular | GSM / GPRS |
| Power | CR2450 lithium cell, 3 V nominal, independent of the metrology |
| Protection | |
| Ingress protection | IP68 meter face · IP65 telemetry cover |
| Compliance | |
| Metrology | MID 2014/32/EU (MI-001), EN ISO 4064 |
| Radio | RED 2014/53/EU for telemetry variants |
| Marking | CE |
Full product documentation
Open the product passport, technical specifications, EU declaration of conformity, RoHS declaration, and test reports on our documentation portal.
